Krushi Savya Organic Carbon Tester (KSOC Tester) Complete Specification of the Krushi Savya Organic Carbon Tester

1. Title of the Invention

Krushi Savya Organic Carbon Tester (KSOC Tester)

2. Field of the Invention

The present invention relates to the field of agricultural soil testing, specifically to a rapid and user-friendly method and kit for determining the organic carbon content in soil.

3. Background of the Invention

Organic carbon is a fundamental component of soil productivity and plays a crucial role in environmental cycles. Approximately 80% of the world’s total organic carbon is stored in the first meter of soil depth. It directly impacts crop health and production, provides food for microorganisms, regulates the supply of water, air, and essential nutrients to plants, and helps in sequestering carbon dioxide from the atmosphere, thus mitigating climate change. Current agricultural practices, including excessive use of chemicals and improper crop management, have led to a significant depletion of soil carbon, resulting in severe consequences for soil health and productivity. There is a critical need for an accessible and efficient method for farmers to monitor and manage soil organic carbon levels to promote sustainable agriculture and ensure a secure future.

4. Summary of the Invention

The Krushi Savya Organic Carbon Tester is a single-use, rapid test kit designed to enable farmers to easily determine the primary organic carbon content in their soil. The kit provides a quick assessment of soil fertility, enabling informed decisions regarding the use of organic and natural fertilizers, reducing reliance on chemical fertilizers, and improving overall soil health, crop yield, and environmental sustainability.

5. Detailed Description of the Invention



5.1 Components of the Krushi Savya Organic Carbon Tester Kit

The kit comprises the following essential components:

•     Two Reagent Bottles:

○     KSOC1: A solution used to initiate the reaction with the soil sample. ○     KSOC2: An acidic solution that reacts with the organic carbon in the soil, leading to a color change. (Caution: Handle with care, as it is acidic; protective gloves are provided and recommended).

•     One Small Bottle:

○     KSOC3: A liquid added to the solution after the initial reaction to complete the color development process.

•     Glass Beaker: A transparent container for mixing the soil sample and reagents.
•     Spoon-Syringe: A measuring tool designed to accurately weigh 0.5 gm units of the soil sample.
•     Rubber Gloves: For hand protection during the testing process, especially when handling KSOC2.
•     Plastic Bag: For collecting and preparing the soil sample.
•     Color Chart: A visual reference chart with different color shades corresponding to various percentages of organic carbon content.

5.2 Method of Operation (Testing Procedure)

The testing procedure involves the following steps:

5.2.1 Soil Sample Collection

1.   Area Selection: Divide the farm into uniform sections based on area, soil structure, color, and previous crops.
2.   Sample Collection: Using a spade, dig a ‘V’ shaped pit 15 cm deep in the soil. Collect a thin slice of soil from both sides of the pit, from top to bottom. Repeat this process at 8 to 10 different locations across the selected section.
3.   Mixing and Quartering: Collect all the soil samples, mix them thoroughly, and divide the mixture into four equal parts. Discard two opposite parts. Re-mix the remaining two parts, and repeat the quartering process until a manageable sample size is obtained.
4.   Preparation for Test: Place the final mixed soil sample into the provided plastic bag. If the soil is wet, it must be dried before testing.



5.2.2 Testing Procedure with the Kit

1.   Preparation: Take the provided glass beaker.
2.   Soil Measurement: Use the spoon-syringe to measure 0.5 gm mark of the soil sample.
3.   Initial Reaction (KSOC1): Transfer the measured soil sample into the beaker. Add the solution from the KSOC1 bottle to the beaker.
4.   Acidic Reaction (KSOC2): Add the KSOC2 solution to the beaker. Carefully and slowly mix the contents, ensuring to wear the provided rubber gloves as KSOC2 is acidic.
5.   Waiting Period: Allow the reaction to proceed for 10-15 minutes.
6.   Color Development (KSOC3): Add the entire contents of the KSOC3 liquid to the solution in the beaker. Wait for a short period for the color to stabilize.
7.   Color Matching: Compare the color of the clear liquid at the top of the beaker with the provided color chart. Identify the closest or exact match on the chart.
8.   Result Interpretation: Note the percentage of organic carbon (% OC) corresponding to the matched color on the chart. This indicates the organic carbon content in the soil.

5.3 Interpretation of Results and Recommendations (Color Chart and Recommendation)

The color chart provides approximate % OC ranges and corresponding recommendations for soil management:

% OC Range (Approx.)	Classification	Recommendation
< 0.30	Very Low	• Add abundant organic fertilizers like farmyard manure, compost, vermicompost, Jeevamrut, and Ghanjeevamrut. • Practice green manuring: Grow crops like sunn hemp, dhaincha, cluster bean, or other leguminous crops and incorporate them into the soil at the flowering stage.
0.30-0.60	Low	• Adopt crop rotation, including leguminous crops. • Avoid leaving the soil bare for long periods; use cover crops. • Reduce chemical fertilizer use and increase the application of organic/natural fertilizers.
0.60-1.0	Medium	• Continue regular use of organic/natural fertilizers. • Continue practicing green manuring and crop rotation. • Attempt minimum tillage practices to maintain soil vitality. • Incorporate crop residues into the soil instead of burning them. <br> • Use organic/natural fertilizers and organic/natural pesticides to maintain soil health.
> 1.0	Excellent	• Continue using appropriate amounts of organic/natural fertilizers to maintain this level of organic carbon in the soil. • Adopt sustainable farming practices like crop rotation, mixed cropping, and minimum tillage. <br> • Avoid or minimize the use of chemical fertilizers and pesticides as much as possible.

6. Applications of the Invention

The Krushi Savya Organic Carbon Tester has several significant applications:

•     Soil Health Assessment: Provides a quick and easy way for farmers to understand the primary organic carbon content, indicating soil fertility.
•     Optimized Fertilizer Management: Helps farmers determine the appropriate quantity of organic/natural fertilizers (e.g., farmyard manure, vermicompost, green manure) to use based on the organic carbon level, thereby reducing chemical fertilizer expenses and environmental damage.
•     Nutrient Availability Indicator: A low carbon level suggests potential deficiencies in essential nutrients like nitrogen, phosphorus, and sulfur, as organic carbon aids in holding and slowly releasing these nutrients to plants.
•     Soil Improvement Strategies: Based on the test results, farmers can adopt practices like incorporating crop residues, agroforestry, or organic farming methods to improve soil health.
•     Increased Production and Quality: Healthy soil, supported by optimal organic carbon levels, leads to better crop yields and quality, increasing farmer income.
•     Water Conservation and Environmental Benefits: Improved organic carbon content enhances soil water retention capacity, leading to water savings and contributing to environmental benefits by absorbing carbon from the atmosphere.

7. Advantages of the Invention

•     Simplicity: Easy to use by farmers with minimal training.
•     Rapidity: Provides results within 10-15 minutes.
•     Cost-Effectiveness: A single-use kit makes it an affordable solution for on-site testing.
•     Empowerment of Farmers: Enables farmers to make informed decisions about soil management without relying solely on external laboratories for basic organic carbon assessment.
•     Environmental Friendliness: Promotes sustainable farming practices by encouraging the use of organic fertilizers and reducing chemical inputs.

8. Limitations

This test primarily provides an estimate of organic carbon content. For a comprehensive and precise soil analysis report with accurate recommendations, it is advised to send the soil sample to a specialized laboratory like Krushi Savya Agri Clinic.

9. Conclusion

The Krushi Savya Organic Carbon Tester is a revolutionary initiative for farmers, providing a practical and immediate tool to assess and manage soil organic carbon, thereby fostering healthier soils, higher yields, and more sustainable agricultural practices.
